LED Sphere

LED Sphere

Captivate your audience with a full motion LED Video Sphere.

LED Sphere - Video Sphere

What can you do with 360 LED video sphere displays?

LED Video Spheres are capable of full motion video on the entire globe. As with any technology there are requirements and specifications to follow. With your video sphere we will provide you with instructions and a manual to assist you in content creation and formatting.

What you will choose to use your sphere for is up to your requirements and vision, we have seen clients incorporate video technologies into one of a kind amazing experiences. Incorporating 360 video into your Event, Meeting, Trade-show, Museum, or Corporate Facility will leave a lasting impression.

Extra Large LED Video Sphere

LED Sphere Sizes

LED Sphere Standard Size List

Below is a list of standard size digital video spheres. We have listed the standard sizes available in both Inches and Meters.

Should you have any questions regarding sizes, pixel pitch or pricing please contact us at 888-631-5880

XR2.5XR3XR4XR5XR6
32” / 0.8m32” / 0.8m32” / 0.8mCallCall
39” / 1m39” / 1m39” / 1m39” / 1mCall
48” / 1.2m48” / 1.2m48” / 1.2m48” / 1.2mCall
60” / 1.5m98” / 2.5m60” / 1.5m60” / 1.5mCall
Call118” / 3m70” / 1.8mCallCall
CallCall78” / 2.0CallCall
CallCall86” / 2.2mCallCall
CallCall98” / 2.5mCall98” / 2.5m
CallCall118” / 3mCallCall

Floor Mount or Suspended Sphere Mounting

Mounting digital video sphere is quick and easy with either Suspension or Base Supported.

Your new LED sphere is comprised of not only LED technology but also a sturdy frame system inside to allow for flexible and sturdy mounting options.

  • Suspension Mounting your sphere can be done with a Pole, Chain, Cable etc., be sure to follow local codes but this is a great way to get the display off the ground and in the air. The internal frame structure is designed to accommodate suspension mount applications.
  • Base Mounting your sphere can be done with a standard pipe and allows you to lower the sphere onto the pipe, the pipe will bottom out and support the sphere with the internal structure.

Either mounting option will offer minimized pixel loss with our mounting hole cover panels. These custom panels will install over the hole and provide a seamless experience for the top or bottom of the video sphere.

Digital Video Spheres Suspension

LED Spheres Packaging

LED Sphere Shipping

Shipping your LED Sphere anywhere in the world is possible with our crating solution that ensures safe travel and delivery to your destination.

Our shipping crates or made to deliver your LED Sphere to one location or even several locations. When it comes to shipping you never know what may happen so we do what we can to protect the sphere while in transit.

Sturdy wood crates are built with integrated pallet skid bottom so you can move around with a forklift or pallet jacket. Once you are ready to install or test your new sphere you will remove the side and top to access the sphere.

Should you have any questions or requirements regarding your crate, please contact a team member for more information and details.

LED Sphere Power and Ethernet Connection

LED Sphere setup and connection is comprised of 3 actions.

  1. Sphere Mounting (mentioned above)
  2. Sphere Power Connection
  3. Sphere Video Source ~ Ethernet Cable Connection

Sphere Mounting is either a Pole/Base Mount or Suspension Mount

Sphere Power Connection is standard 110v/220v power connection. Most of our LED Spheres are capable of utilizing (1) standard outlet or electrical circuit for the sphere display. For instance a 39″ P4 sphere power draw is minimal and you can run 2 of these on 1 standard circuit. Please contact SSI for specific power requirements for your Size/Resolution sphere.

Sphere Video Source is connected by Ethernet Cable from your Computer to your LED Sphere. We supply the required components for the Ethernet cable connection to transmit video to your sphere. Please contact SSI for specific information regarding video connection to your sphere.

Resolution and Pixel Pitch

Because this is an LED based spherical display it is important to understand that Pixel Pitch and Sphere Size are both factors when determining resolution.

Please contact SSI to discuss specifics related to LED Sphere Resolution.

SSI offers standard LED Spheres in XR2.5, XR3, XR4, XR5 and XR6 Pixel Pitch.



Learn more about pixel pitch and LED technologies at Distinct LED

Digital Video Sphere Integrated onto Lighpole
